Monochrome production

Although more and more print products are requested in full color, there are still good reasons for black-and-white digital machines. Both the majority of all books content pages and most of todays personalized elements are still printed black-and-white and can be produced most cost-efficiently with a dedicated monochrome digital machine like the Versafire LM from HEIDELBERG.

Key features at a glance

  • High throughput up to 4,080 A3 sheets/hour or 136 A4 sheets/minute (simplex)
  • Quality reproduction with 2,400 × 4,800 dpi black-and-white
  • Wide media flexibility for new applications
  • Double toner cartridge bay for uninterrupted production
  • Optional scanning up to 220 A4 pages/minute
  • High availability due to max. 13,850 sheets tray capacity
  • New applications with printing banner up to 700 mm material
  • Printing-on- Demand with optional finishing solutions

Technical data

Engine and controller
Engine
  • 2,400 × 4,800 dpi black & white
  • wax-based PxP™ toner
  • Vacuum feeder (optional)
  • 17” touch screen
  • Oilless belt-fusing method
  • up to 13,850 sheets load capacity
Scanner
  • 600 dpi (optional), 8 bit
  • 120 A4 pages/min (simplex)
  • 220 A4 pages/min (duplex)
Controller
  • EFI Fiery EB-35

Media format
Media format min. width × length
  • 100 × 140 mm (3.93 × 5.51 in)
Media format max. width × length
  • 330 × 488 mm (12.99 × 19.21 in); with banner tray up to 700mm (27.5“)
Printing speed and material
Printing speed
(independent of material thickness)
  • 4,080 A3 sheets/hour or 136 A4 pages/minute (simplex) optional
  • 3,330 A3 sheets/hour or 111 A4 pages/minute (simplex) optional
Print material*
  • Plain paper, coated paper (gloss & matt) recycled paper, pre-printed offset, letterhead, prepunched, Tab Stock, OHP (Transparency), translucent paper, envelopes, metallic, synthetic, water-resistant, magnetic or label (adhesive), NCR (carbon copy) substrates
Grammage
  • 40 – 350 gsm (duplex)
Average monthly print volume
  • 111ppm: 75,000 – 250,000 A3 sheets/month (simplex)
  • 136ppm: 125,000 – 300,000 A3 sheets/month (simplex)
Max. monthly print volume
  • 500,000 A3 sheets/month (simplex) up to 5 years
*Not all media approved
Hardware and options
Weight
  • max. 428 kg (engine)
Dimensions (W × D × H)
  • Width 1,735 × Height 1,141 × Depth 900 mm (68.30 ×44.92 × 35,43 in)
Power consumption
  • < 3,150 Watts
Options
  • Up to 2 Large Capacity Tray, cover interposer, multi folding unit, perfect binder, ring binder, booklet finisher, Plockmatic High Capacity Interposer
