The Ecofoil 106 FC combines precise foil application with high productivity to meet the needs of ambitious packaging printers. With a foiling pressure of up to 300 tons and speeds of up to 7,500 sheets per hour, it enables high-quality hot foil stamping, embossing, and optional holographic effects. Advanced control and monitoring features ensure reliable operation, while optimized foil usage can reduce material consumption – resulting in lower costs and increased output of additional sheets.
The Ecofoil 106 FC offers many benefits to commercial and packaging printers alike.
Up to 300 tons of pressure and 7,500 sheets/hour deliver reliable results for hot foil stamping, embossing, and optional holographic effects – ideal for growing packaging businesses.
Smart foil feed control helps save foil, reducing operating costs and supporting sustainable production.
Consistent high-precision registration for detailed foil work, clean embossing and premium visual effects across a wide range of folding carton applications.
Improved efficiency and short setup times help boost output by up to 3 million sheets per year, maximizing ROI in daily production.
Intuitive control system, centralized monitoring and ergonomic machine layout ensure smooth operation and quick onboarding for new users.
| Sheet size (max.) | 760 x 1,060 mm (29.92 x 41.73 in) |
| Sheet size (min.) | 360 x 450 mm (14.17 x 17.72 in) |
| Cutting pressure (max.) | 300 t |
| Max. height feeder pile (incl. Pallet) | 1150 mm (45.28 in) |
| Max. height delivery pile (incl. Pallet) | 1000 mm (39.37 in) |
| Paper (min.) | 90 g/m² (26.5 lb/1000 ft²) |
| Carton board (max.) | 2,000 g/m² (590 lb/1000 ft²) |
| Corrugated (max.) | 4.0 mm (0.157 in) |
| Dimensions of the machine (LxBxH) | 5,930 x 4,475 x 2,325 mm (233.46 x 176.18 x 91.54 in) |
| Running speed (max.) | 7,500 sheets/hour |
| Hot Foil stamping speed (max.) | 6,500 sheets/hour |
| Temperature (max.) | 180 °C (356 °F) |
| Numbers of heating zones | 20 |
| Foil reel diameter longitudinal (max.) | 250 mm (9.84 in) |
| Foil reel diameter transversal (max.) | 200 mm (7.87 in) |
| Foil width | 20 – 1,020 mm (0.79 – 40.16 in) |
The Ecofoil 106 FC is developed and manufactured by the skilled team at Masterwork and is exclusively sold and supported through the global network of trusted sales and service professionals from HEIDELBERG.
